Aquapini and Walipini Open Source Hub

As part of One Community’s four-phase strategy and global change methodology, our Phase II Highest Good food infrastructure is an open source project-launch blueprinting of 6 structures that will represent 3 different in-ground, enclosed designs for food production. These 6 structures will be a part of our botanical garden model and will produce a diversity of delicious and nutritious food far beyond anything found in a typical grocery store. This open source hub includes the following sections:

NOTE: THESE DESIGNS STILL NEED WORK. THIS PAGE IS NOT CONSIDERED BY US TO BE
A COMPLETE AND USABLE TUTORIAL UNTIL WE BUILD AND TEST THE AQUAPINI AND ADD
ALL THE RELATED VIDEOS AND EXPERIENCE FROM
THAT BUILD TO THIS PAGE. IN THE MEANTIME, WE WELCOME YOUR INPUT AND FEEDBACK AND INVITE YOU TO JOIN THE TEAM AND HELP FINISH THE DESIGNS IF OPEN SOURCE AQUAPINI/WALIPINI DESIGN IS SOMETHING YOU ARE INTERESTED IN

RELATED PAGES (Click icons for complete pages)

highest good food, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, vegan, vegetarian, omnivore, diet, food infrastructure, hoop houses, large scale garden, food forest, botanical garden, soil amendment, ziconsLarge-scale Gardening Icon, food diversity, organic food, eco-living, grow your own foodHoop House Open Source Hub Iconsustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7bfood forest, growing food, great food, natural food, open source food, One Community food, Canopy, Understory, Vines, Shrubs, Herbs, Groundcover, Root Crops, Edge Plantings, organic food, delicious food, botanical garden, grow your own food
botanical garden, open source botanical garden, preserving bio-diversity, regenerative living, earth-regenerative, species diversity, Highest Good for plants, One Community, open source plant model, preserving plant diversity, saving plants, loving plants, global plant collaborative, indoor garden, walipini, aquapini, non-profit support for agriculture, food research, plant researchSketchup Trees, Sketchup plants, how to use sketchupopen source, open source sustainability, open source world, free sharing, creative commons, forwarding innovation, sharing, collaboration, cooperation, sustainable communities, teacher demonstration hubs, One Community Global, One Community, green living, Highest Good food, Highest Good housing, Highest Good economics, Highest Good society, Highest Good living, Highest Good lifestyles, Highest Good for Alltransforming the global environment, transformational change, evolving living, One Community, One Community Global, creating a new world, the solution to everything, the solution to everything, the solution to anything, creating world change, open source future, for The Highest Good of All, a world that works for everyone, world change, transforming the planet, difference makers, sustainability non-profit, solution based thinking, being the change we want to see in the world, making a difference, sustainable planet, global cooperative, 501c3 sustainability, creating our future, architects of the future, engineers of the future, sustainable civilization, a new civilization, a new way to live, ecological world, people working together, Highest Good food, Highest Good energy, Highest Good housing, Highest Good education, Highest Good societyliving and creating for The Highest Good of All, global transformation, making a difference, good for people, good for the planet, good for the economy, good for everyone, the solution to everything



WAYS TO CONTRIBUTE TO EVOLVING THIS SUSTAINABILITY COMPONENT WITH US

SUGGESTIONS     ●     CONSULTING     ●     MEMBERSHIP     ●     OTHER OPTIONS

CLICK HERE TO HELP US FINISH THE OPEN SOURCE DESIGNS FOR THESE STRUCTURES



WHAT IS A WALIPINI, AQUAPINI, AND ZENAPINI?

open source building plans, open source architectural plans, open source structural plans, open source blueprints, open source CAD, open source Sketchup, open source 3D Max, open source Revit, free-shared plans, free-shared blueprints, sustainable food, best practice food, sustainable food systems, green food, aquapinis, aquapini, walipini, green house, in-ground growing, organic food, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, build your own food house, build your own greenhouse, affordable food, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, eco-housing, artistic homes, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community housing, Highest Good housingA walipini is an affordable, in-ground, in-door food production structure, resembling a greenhouse. An aquapini is a walipini incorporating aquaponics which lends itself to large-scale food production. A zenapini is an aquapini with a focus on aesthetics and food diversity. These structures are built into the ground because below the frost line the earth maintains a stable temperature of 55 deg F (13 deg C) year round. This helps keep these structures cool in the summer and warmer in the winter. They have additional benefits in that they require less building materials than a greenhouse, look better and maintain a lower physical profile, and are easier to service and repair since the roof begins at about ground level.

Our design includes the following 6 structures that provide different internal environments to grow a diversity of locally produced food that is not possible to grow outdoors in our location:

All of these growing environments are designed to maximize growing space, grow an unparalleled diversity of food, and provide a beautiful recreational space as well. This is possible by using a combination of a sloped South-terraced growing area, completely glazed South wall, and skylights. Our design maximizes needed sunlight in the winter and reduces excess sunlight (and heat) in the summer. An overhead view of the overall design is shown below.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Complete Walipini, Aquapini, and Zenapini Infrastructure Layout in CAD: Click to Enlarge

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Complete Infrastructure Concept Render – Click to Enlarge

The key features and intentions of the walipini, aquapini, and zenapini (Phase II) food infrastructure include:

  • 6 structures
  • Artistic designs
  • Multi-functional
  • ADA accessibility
  • Support our own bee colony
  • Central amphitheater space
  • Rainwater collection from all structures
  • 1 large-scale food production aquapini
  • 3 maximally affordable walipinis purposed for trees
  • 2 zenapinis purposed for diversity and aesthetic beauty
  • Enough food production for all of One Community and our visitors
  • Provides system redundancy to guarantee sufficient food production
  • Sufficient distance between all structures to avoid shading of other structures
  • Easy foot travel (with small climb) from any point to any other
  • Central pond for water storage, aesthetic benefit, edible water plants, and wading/swimming
  • Easy lateral expandability in support of our open source goals for adaptability to individual needs



WHY BUILD WALIPINIS, AQUAPINIS, AND ZENAPINIS?

open source building plans, open source architectural plans, open source structural plans, open source blueprints, open source CAD, open source Sketchup, open source 3D Max, open source Revit, free-shared plans, free-shared blueprints, sustainable food, best practice food, sustainable food systems, green food, aquapinis, aquapini, walipini, green house, in-ground growing, organic food, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, build your own food house, build your own greenhouse, affordable food, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, eco-housing, artistic homes, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community housing, Highest Good housingIn accordance with our botanical garden model and our for The Highest Good of All philosophy, we will demonstrate what truly ethical and carefully planned land stewardship can accomplish. The ultimate result of this will be sustainable production of unparalleled nutrition and diversity capable of providing enough volume and variety to feed all of One Community and our visitors. Even with traditional methods one person working full-time on food production can produce enough food to feed 30; with aquaponics that same person can produce enough food to feed 300. Our goal when arriving on the property is to immediately start large-scale gardening and building ultra-affordable, easy, and fast to construct hoop houses. We will build enough hoop houses and plant enough food to make ourselves about 70% food self-sufficient within 3-4 months. Combining this with raising goats, chickens, and rabbits will provide sufficient food to feed 100+ people by the end of the first year. Until we are successfully producing enough food to sustain ourselves, we will buy it from local producers and suppliers with the goal of supporting sustainable and ethical practices.

We chose walipinis, aquapini, zenapinis for our Phase II food production infrastructure because they are affordable to construct, easier than other models to control the internal temperature, can produce large volumes of year-round food, and because we feel they provide the maximum benefit to financial and labor investment ratio. This makes Walipini, Aquapini, and Zenapini designs the best choice in support of our four-phase global transformation strategy and open source project-launch blueprinting goals. The complete layout of these structures is also ideal for water catchment and conservation, creates a central recreational space, and provides extremely efficient harvesting and food removal. Once we start building these structures, the first two are estimated to take no more than 6 months to build and test and another 2 months or so to begin producing food. All six structures should be able to be completed within a year.



WAYS TO CONTRIBUTE TO EVOLVING THIS SUSTAINABILITY COMPONENT WITH US

SUGGESTIONS     ●     CONSULTING     ●     MEMBERSHIP     ●     OTHER OPTIONS



CONSULTANTS ON THESE OPEN SOURCE DESIGNS

Avery Ellis: Aquaponics Specialist and owner/operator of Integrated Aquaponics
Bear Stauss: Horticulturalist and Landscape Design/Recreation Area Management Specialist
Bupesh Seethala: Architectural Drafter & Designer, BS Electrical Engineering (BupeshSeethala.com)
Charles McLean: Architecture & Urban Agriculture Designer, Professor, and owner of OM Greengroup
David Sweet: Architect (DSweet.biz)
Daniela Andrea ParadaCivil Engineering Student
Diana Gomez: Mechanical Engineer
Douglas Simms Stenhouse: Architect and Water Color Artist
Henry Vennard: Mechanical Engineer
Jiayu Liang: Landscape Designer
Kim Braman: Apiary and Beekeeping Expert
Mohammad Almuzaial: Civil and Construction Engineer
Ron Payne: HVAC / Thermal Designer, Mechanical Engineer
Zdenek Jurik: P.E. Structural, Civil and Mechanical Engineer and founder of ABC Engineering



WALIPINI, AQUAPINI & ZENAPINI
OPEN SOURCE PORTAL AND DIRECTORY

project management software, open source software, teacher/demonstration village, objective fulfilled living, data gathering for The Highest Good, transforming the planet, global collaboration, working together, tangible time, One Community, ACE Application Open Source Hub, Open Source ACE, ACE ApplicationWe are starting by researching, developing, and open source and free-shared project-launch blueprinting three different sustainable food production systems: 3 separate maximally-affordable walipini greenhouses, a large-scale food production aquapini, and 2 different “backyard version” zenapini designs. As we build them, solve problems, and evolve each of them for One Community (and with others around the world) we will use this page as the portal to all the open source and free-shared project-launch blueprinting details needed for duplication of these systems including:

spacer the One Community blog, One Community updates, transforming the global environment, transformational change, evolving living, One Community, One Community Global, creating a new world, the solution to everything, the solution to everything, the solution to anything, creating world change, open source future, for The Highest Good of All, a world that works for everyone, world change, transforming the planet, difference makers, sustainability non-profit, solution based thinking, being the change we want to see in the world, making a difference, sustainable planet, global cooperative, 501c3 sustainability, creating our future, architects of the future, engineers of the future, sustainable civilization, a new civilization, a new way to live, ecological world, people working together, Highest Good food, Highest Good energy, Highest Good housing, Highest Good education, Highest Good society What we’re working on now
sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b What to grow and how
aquapini and walipini building plans, aquapini and walipini construction plans, aquapini, walipini, building plans, zen aquapini, walipini greenhouse, growing zones, tropical aquapini, desert house, borderline subtropical house, tropical house, cloud forest house, tropical moist house, planting maps, large scale production, concept render Construction Plans and Documents
aquapini materials costs, walipini materials costs, earthbag materials costs, straw bale materials costs, eco-materials, green materials, building materials, where to get materials, construction materials, earthship materials, sustainable materials, subterranean construction materials, architecture materials, eco-materials, tree-house materials, earthblock materials, earth block materials, building with earth, building with straw, sustainable materials, Highest Good materials, sourcing materials, buying materials Detailed materials list and cost analysis for all components
Aquapini and Walipini DIY multi-media resource hub, aquapini, walipini, do it yourself, DIY, resource hub, zen aquapini, walipini greenhouse, growing zones, tropical aquapini, desert house, borderline subtropical house, tropical house, cloud forest house, tropical moist house, large scale production, how to build, building videos, building PDFs, building instructions, how to build with cob, how to build with earth, how to build with earthbag, how to build with tires, how to build with earthblocks, how to build with earth block, how to build with straw bales, how to build with subterranean construction, how to build with clay, DIY videos, DIY audio, DIY tutorials, DIY resources, DIY tools, DIY education Do-it-yourself multi-media resource and information hub
aquapini and walipini licensing and permitting, aquapini licensing, walipini licensing, aquapini permitting, walipini permitting, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b, aquapini, walipini, permitting, licensing, government, resource hub How to work with local government if permitting is needed
aquapini and walipini tools and equipment, aquapini tools, walipini tools, aquapini equipment, walipini equipment, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b, aquapini, walipini, tools, equipment, resources, cost analysis Detailed tools and equipment list, best place to buy, and cost analysis for all components
aquapini and walipini build-time and labor investment, aquapini build time, walipini build time, aquapini building time, walipini building time, aquapini how long to build, walipini how long to build, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b, aquapini, walipini, time investment, projections, build time Detailed build-time investment needs for each component based on our building experience
water conservation methods, advantages of rainwater harvesting, rainwater harvesting techniques, open source water systems, methods of rainwater harvesting, smart water, intelligent water use, swails, One Community, solution based thinking, conserve water, water conservation, water wise, saving water, best land for water, mulch, water catchment, water collection, swails, water collecting, vermiculture, conserving water How to install and utilize water catchment for each structure and the complete food infrastructure
aquapini and walipini problem solving guide, aquapini solutions, walipini solutions, aquapini answers, walipini answers, help with aquapinis, help with walipinis, aquapini build time, walipini build time, aquapini building time, walipini building time, aquapini how long to build, walipini how long to build, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b, aquapini, walipini, problem solving guide, solution hub, troubleshooting guide How to make your build easier than ours and how to solve any problems we encountered in our build
aquapini and walipini maintenance and upkeep, aquapini maintenance, aquapini upkeep, walipini maintenance, walipini upkeep, aquapini solutions, walipini solutions, aquapini answers, walipini answers, help with aquapinis, help with walipinis, aquapini build time, walipini build time, aquapini building time, walipini building time, aquapini how long to build, walipini how long to build, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b, aquapini, walipini, maintenance and upkeep Complete and on-going maintenance and upkeep details per our experience with all village components
aquapini and walipini other people's projects, collaborative hub, aquapini, walipini, collaborative hub, other peoples projects, others building earthbag, others building with straw bale, others building earth block, others building tree houses, others building greenhouses Archive and database of others building similar structures including their experiences, adaptations, etc.
aquapini and walipini everyone who helped, aquapini collaboration, walipini collaboration, aquapini cooperation, walipini cooperation, help with aquapinis, help with walipinis, aquapini build time, walipini build time, aquapini building time, walipini building time, aquapini how long to build, walipini how long to build, sustainable food, best practice food, sustainable food systems, aquaponics, walipini, aquapini, zen aquapini, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, grow your own food, build your own greenhouse in the ground, ground greenhouse, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, food anywhere, maximum food diversity, build your own farmers market, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community Update, USDA zone 7a, USDA zone 7b, aquapini, walipini, consultants, highest good food consultants, everyone who helped List of everyone who helped us design and build this so they can be contacted to help with modifications
Highest Good housing, cob construction, earthbag construction, straw bale construction, earthship construction, subterranean construction, sustainable homes, eco-homes All of the above for all 7 open source complete sustainable-housing village designs
Highest Good energy, green energy, off the grid living, eco-living, going green, sustainable energy All of the above for complete renewable energy infrastructure to power these structures



WALIPINI, AQUAPINI & ZENAPINI
DESIGN DETAILS

how to use this, how to do this, how this works, using this for world change, One Community how-to, DIY instruction, applying this, making use of this, world change with this, One Community Global, teacher demonstration hub, community application

This section contains the following details related to the design of the walipini, aquapini, and zenapini:



DESIGN SUMMARY

Our design consists of six structures that provide six different unique internal growing environments.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Six Unique Indoor Growing Structures – Click for the open source of the spreadsheet

These growing structures will be built in the following order: Aquapini, Walipini 3, Walipini 2, Walipini 1, Zenapini 1, and Zenapini 2. A top view of the overall plan is shown in the image below, along with a video of the overall space and the internal environment for the updated large-scale Aquapini. The internal details for the rest can be seen in the floor plan examples with complete planting plans.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Overhead View Of The Site Layout

video coming…http://www.dropbox.com/s/g64wcum3d690f2m/FINAL%20Aquapini%20%26%20Walipini%20Video%20Walkthrough.mp4?dl=0

Here are the most current Walipini, Aquapini, and Zenapini download files.

CLICK THE IMAGES BELOW FOR ACCESS TO THE RELATED DROPBOX DOWNLOAD LINKS*
Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouseWalipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse
* The information in these files is provided exclusively in accordance with our Terms and Conditions


INSIDE DETAILS

The inside of the structures have terraced growing spaces and a water storage pond. The total planted area of the 3 walipinis, 1 aquapini, and 2 zenapinis totals 10,622 square feet.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

The Breakdown of the Planted Areas for Each Greenhouse – Click for the Open Source of the Spreadsheet

The purpose of the terraces is to maximize growing space in the South region of each structure by providing the ideal slope for maximum sunlight penetration and utilization. The slope is based on the sun study for our location and the sun angle on December 21st, when the sun’s path is lowest on the horizon. The terrace walls measure one foot in width. Furthermore, the curvatures of the terrace provide better sunlight penetration and less shadows during the mornings and evenings. To build this design, earthbags filled with stabilized earth mix were selected as they are easy to work with. Although this project can also be completed with cinder blocks, the approach would make the needed curvatures harder to create.

To make construction as easy as possible, the foundational dimensions of all the structures are identical and can be seen in these images. Additional details on each structure is given in the subsections below.

floor, wall, roof, Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Walipini, Aquapini, and Zenapini Floor, Wall, and Roof Details – Click to Enlarge

Terrace, Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Walipini, Aquapini, and Zenapini Terrace Details – Click to Enlarge



WALIPINI GREENHOUSES 1, 2, and 3

open source building plans, open source architectural plans, open source structural plans, open source blueprints, open source CAD, open source Sketchup, open source 3D Max, open source Revit, free-shared plans, free-shared blueprints, sustainable food, best practice food, sustainable food systems, green food, aquapinis, aquapini, walipini, green house, in-ground growing, organic food, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, build your own food house, build your own greenhouse, affordable food, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, eco-housing, artistic homes, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community housing, Highest Good housingWe will build 3 walipinis as traditional soil growing areas. The purpose of the walipini greenhouses is to provide research and development comparisons with the aquapini and zenapinis. We will open source project-launch blueprinting this maximally affordable, duplicable, and easy to maintain year-round food production option that also houses trees.



WALIPINI #1

Walipini #1 is a Frost-free Arid Zone Desert House providing over 1,800 square feet (167 sq meters) of growing space. The temperature range will be maintained between 60-100 F (16-38 C) with humidity ranging between 50-90%. The plantings in Walipini #1 will be in support of our botanical garden model and based on species from the world’s tropical deserts including (and centered around) specimens of the endangered species Cordeauxia edulis, the yeheb nut.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Detailed Overhead View Of The Walipini 1 – Frost-free Arid Zone Desert House – Click Image to Enlarge and See Planting Plan Details (Values in Image Represent an Appointed Plant Type)

WALIPINI #2

Walipini #2 will be the Borderline Subtropical House also providing over 1,800 square feet (167 sq meters) of growing space. It will maintain cool subtropical and temperate off-season production of plants that will enjoy its temperature and humidity ranges of 32-90 degrees F (0-32 C) and 30-50%, respectively. This house will host many of the types of crops that we will also grow outdoors, including pomegranate, loquat, figs, pineapple guava, olives, grapes, peaches, and apricots.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Detailed Overhead And Rendered Side Views Of The Walipini 2 – Borderline Subtropical House – Click Image to Enlarge and See Planting Plan Details (Values in Image Represent an Appointed Plant Type)

Here’s a 2-minutes video of these conditions already being met successfully with a passive greenhouse in Nebraska:


Here is a 20-minute more detailed version and a PDF download with additional details:

Here’s another walipini example from Colorado. It includes a few other sustainable heating options too:


Here’s an example from Bozeman, Montana:



WALIPINI #3

Walipini #3 will be the Tropical House providing over 2,900 square feet (269 sq meters) of growing space. This structure is the same size and similar internal environment (60-90 degrees F (16-32 C) and 60-90% humidity) as the large-scale production aquapini. Walipini #3 however, does not incorporate any aquaculture. Walipini 3 demonstrates a year-round affordable walipini in-ground growing food production system incorporating a diversity of trees and other tropical plants.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Detailed Overhead And Rendered Side Views Of The Walipini 3 – Borderline Subtropical House – Click Image to Enlarge and See Planting Plan Details (Values in Image Represent an Appointed Plant Type)



LARGE-SCALE PRODUCTION AQUAPINI

open source building plans, open source architectural plans, open source structural plans, open source blueprints, open source CAD, open source Sketchup, open source 3D Max, open source Revit, free-shared plans, free-shared blueprints, sustainable food, best practice food, sustainable food systems, green food, aquapinis, aquapini, walipini, green house, in-ground growing, organic food, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, build your own food house, build your own greenhouse, affordable food, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, eco-housing, artistic homes, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community housing, Highest Good housingThe large-scale production aquapini is a “tropical house,” growing a mix of perennial and annual crops in over 1,900 square feet (177 sq meters) of growing space. Our goal is to demonstrate maximum food production combined with unique biodiversity as part of our botanical garden model. This growing space will maintain an internal temperature range of 60-90 degrees F (16-32 C) and a humidity of 50-80%. The Aquapini produces many foods that cannot be purchased in most grocery stores. It has been designed to maximize the efficient utilization of every possible cubic foot of space, lumen of light, and BTU of heat. Such factors as workflow and ergonomics, light and shade requirements, pollination needs, etc. were carefully considered with the intent to incorporate these elements into a synergistic and harmonious whole. There is also a small recreational space built into the design.

We will post complete and open source Sketchup, and CAD file downloads here for anyone to use and modify as soon as they are complete. Click Here for where we are in the process of completing these files. Click Here to see how you can help us complete them faster.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Detailed Overhead And Rendered Side Views Of The Aquapini – Tropical House – Click Image to Enlarge and See Planting Plan Details (Values in Image Represent an Appointed Plant Type)



ZEN AQUAPINIS (ZENAPINI 1 & 2)

Each of these houses will provide over 1,400 square feet (130 sq meters) of growing space and are designed to demonstrate maximum food diversity and beautiful places to relax. They will be the last of the Phase II food structures to be completed. Our goal with both of these structures is to:

  • Produce a maximum diversity of food and plant life and beauty
  • Function as educational structures as part of our botanical garden model
  • Inspire people with designs they can and will want to build in their backyard

Just one of these zenapini structures produces a volume and diversity of food sufficient for a large family, their friends, and several additional families while also creating an aesthetically pleasing place to go and sit “in nature” even when it’s cold and uncomfortable outside. We are also building these with the long-term intent to demonstrate that we can convert them into walipini permaculture environments once the higher production levels of the aquaponics are no longer needed due to permaculture and the other sustainable food production facilities incorporated into each of the 7 different village models.



ZENAPINI #1

Zenapini #1 will be an education food production Cloud Forest House. The cloud forest environment is characterized by an ecosystem of high humidity (50-80%) and cooler temperatures than tropical regions (55-80 degrees F (13-27 C)) and is generally frost free. As an educational structure and part of our botanical garden model, this house will feature unusual food plants, medicinal plants, species with unusual life cycles, reproduction biology, industrial uses, or other economic applications.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Detailed Overhead And Rendered Side Views Of The Zenapini 1 – Cloud Forest House – Click Image to Enlarge and See Planting Plan Details (Values in Image Represent an Appointed Plant Type)

Zenapini #2 will be planted as a Tropical Moist House hosting a highly diverse range of tropical plants. It will be maintained between 60-90 degrees F (16-32 C) and with 50-90% humidity. Food diversity is being prioritized over food production for this house and it will also host a variety of non-edible rare and useful plants. This structure will be an important component of One Community’s educational infrastructure where people can gain direct experience with some of nature’s plant wonders.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Floor Plan for Zenapini 2: Tropical Moist House – Click Image to visit the related planting plan page with a click-to-enlarge image Enlarge and See Planting Plan Details (Values in Image Represent an Appointed Plant Type)

Each value illustrated in the overhead views of the 6 structures represents an appointed plant type. Specifications for plant types and internal environments of each structure are described in the Walipini, Aquapini, and Zenapini Planting and Harvesting page linked below.



LOCATION & ORIENTATION

The first step in designing indoor growing structures is to understand the sun’s path to maximize sunlight and minimize shade. For our particular location, a sun study was conducted to determine the placement of the 6 structures. The sun study simulation demonstrated the amount of sunlight exposure within the building for winter and summer. The goal is to place the structures such that indoor growing areas are not shaded by surrounding structures or other obstructions that prevent sunlight from penetrating the growing space. For optimum clearance, the structure placement is based on the day when shadows are the longest, which happens when the sun’s path is lowest on the horizon. Using the sun study, it was determined that for our specific site the sun’s path is lowest on the horizon on December 21st.

The video below shows the sun studies for the summer and winter, respectively. During the summer you will notice more hours of sunlight and in the winter you will notice longer shadows.

The screenshots below are from the following two videos: SUMMER | WINTER

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Sun Study Results For December 21st, Which Is When Sun’s Path Is Lowest On The Horizon

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

7am (Sun Begins to Shine into Structures at 7am)

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

3pm (After This Point, the Structure’s Shadows Appear to Impact Sunlight within Structures.)

The structures need a minimum clearance from South to North of 38 feet to eliminate shadows falling on the backs of structures when the sun’s path is lowest on the horizon for our property. Also, the structures will be oriented towards the South so the sloped glazing roofs admit the maximum possible sunlight into the planted areas inside the structures. Roof glazing utilizes a material to increase natural light within a structure by allowing light to penetrate straight down into the space. On December 21st, structures are exposed to the sun from 9:15 am to 5:35 pm.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

South Facing Structures With 38 Feet Of Minimum Clearance



STRUCTURAL DETAILS

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Geologic Map That Illustrates The Types Of Soils In The Immediate Site Location

Each structure is 6 feet deep with sloped roofs. The roofs have a rise of 2 feet in elevation per a run of 12 feet, which equates to a 17% slope. The growing area is the open, native soil, meaning that the property soil is utilized within the greenhouses.

The native soil with the largest surface area is eolian and alluvial sand (Qea). Eolian sediments are mainly composed of silt and sand sized particles, while alluvium is a sand composed of silty clay and sandy silt. Overall, mixed eolian and alluvial sand is mostly sand with minor amounts of clay, slit, and gravel. Sandstone (Jt), alluvium (Qa), limestone/limey shale (Jcc), and Navajo sandstone (Jn) are also found on the site, but less prominent. Since Qea is mostly sand with minor amounts of clay and silt, the USDA Textural Soil Classification is sandy loam.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Qea (Sand + Minor Amounts Clay And Silt) Is Sandy Loam

The site geology is also crucial for the foundation design, as it relates to the columns supporting each structure. Additionally, soil characteristics provide engineers with additional insight for rainwater runoff flow, more efficient roadway designs, and vegetation types the soil can naturally supplement. For instance, sandstone weathers into silty loam, while shale weathers into either silty loam, silty clay loam, or silty clay (Carter, 1931). This aspect affects various design elements because weathering will produce unconsolidated material which forms soil that a system has to withstand now and after the results of weathering. A more definite analysis of the existing native soil types will be developed once the exact locations of the greenhouses are specified. Current designs are based on the assumption of sandy loam, a soil type composed primarily of sand and clay.

For a longer life span of the structure, the structural frame will be composed of galvanized steel. This material withstands wind loads, retaining wall loads, and rust. Additionally, isolated concrete footings were chosen because it optimizes cost efficiency and material can be mixed on site, as opposed to bringing cement trucks.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

The Structural Design

The walls of the Walipini, Aquapini, and Zenapini can be constructed with earthbags or cinder blocks. Both building materials are considered structurally sufficient for this application. The entryways to the structures are accessible using paved pathways. In plan view, entrances to each structure are semi-circles. This layout is constructed by retaining walls in order to aesthetically enhance the architectural design and make small-vehicle access to the doorways easier.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Plan-View of Entry Areas for Aquapini, Walipinis, and Zenapinis

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Entryway for Aquapini, Walipinis, and Zenapinis

To establish a good foundation for the growth of produce, open soil with stone walkways are utilized for the floor of these structures.

The glazing of the roofs use SolaWrap, a greenhouse plastic that saves energy, protects against UV rays, and has a lifespan of over 15 to 25 years. This material weighs 410 g/m2 (0.084 lb/ft2). SolaWrap diffuses (spreads out) up to 83% of light, and transmits 83% of light. The transparency of SolaWrap allows for a faster plant growth rate and extends the growing season. SolaWrap is strong enough to withstand wind loads up to 100 mph, making it a durable and energy saving material. The roofing material details are the same for smaller structures (namely Walipini 1, Walipini 2, Zenapini 1, and Zenapini 2) and the same for the larger structures (namely Walipini 3 and the Aquapini). Beams needed for roofing are detailed below.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Roofing Material Details – Click for the Open Source of the Spreadsheet



WATER

Each planted square foot requires about 0.5 gallons of water. Each structure’s daily consumption estimates are based on the planted area and the gallons required per planted square foot. The largest structure, Walipini 3, demands the most water. Collectively the total water consumption is 5,418 gallons per day. An additional 15% of water is included within this value as a precautionary measure. Therefore, the daily total water consumption is 6,170 gallons and monthly is 187,669 gallons.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Daily Water Consumption Per Structure and Overall – Click for the Open Source of the Spreadsheet

The water needs are satisfied by way of swales, rainwater catchment, and an off-site, naturally replenishing storage pond. Swales are sunken or depressed sections of land intended to slow and/or channel rainwater runoff to increase water penetration. There are 6 water-collecting swales in total. Each swale is located at the base of the terraced berms on the side of the structures that do not have glazed walls. The swales of the shorter structures measure 80’ x 3’ and the 2 for the longer structures measure 100’ x 3’. These have drains that feed water to the central storage pond. These swales are for catchment and permeation during large rain events that could cause runoff from the terraces.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Our site receives 12 inches of annual precipitation and if all the rainwater could be captured, the following rule of thumb applies: 1 gallon of water is collected per ft2 for every inch of rain. Rainwater collection is not 100% efficient though. Different surfaces have different collection potentials, like grass only captures 22% because most of the rainwater infiltrates into the ground before it runs off into the rainwater collection storage areas. Even a pond only has 90% collection efficiency because of splashing, and evaporation losses. Information about the rainwater collection surfaces and annual precipitation were used to determine that 4,512 ft3 (33,752 gallons) of rainwater can be harvested per month. Given the monthly water needs of over 32,000 ft3, the rainwater alone does not meet estimated, albeit high, watering requirements. Multiple water conservation measures will be implemented, such as hugelkultur and other methods to reduce the estimated water needs as much as possible.

There was an attempt made to design a central pond that held a 6-month supply, namely 150,526 ft3 (1,126,013 gallons), but it was determined that the volume of water needed was too large. Once we realized we’d need to have an external pond for our water needs, the central pond was redesigned for easy roadway access around it and with a smaller diameter to be more easily covered so it can be used as a stage for music and other presentations.

The property has a natural pond southwest and adjacent to the proposed walipini, aquapini, zenapini location. The plan is to dam this external storage pond better and increase its volume with swales and other harvesting methods. The existing natural pond has a capacity of 54,373 ft3 and will be expanded to a capacity equivalent to 150,000 ft3 to maintain a 6-month supply. The external pond will be replenished by way of the dam or fed from a well.

The primary purpose of the central pond is to function as a distribution water storage for irrigation. The swales and rainwater gravity feed to this central pond. Paved areas have a slope of 2% towards the central pond, therefore allowing the water to drain. The structures are created with slanted roofs and designed with a change in elevation of 2 feet for every 12 feet so as to direct the water on to the paved areas and then to the central pond. Overflow water from the central pond gravity feeds to an external natural pond outside the Walipini, Aquapini, and Zenapini footprint. A pump in the external natural pond will be used to refill the central pond, if needed.

The central pond has a diameter of 24 feet 8 inches and a depth of 8 feet. Harvested rainwater from surrounding structures and runoff from pavement all supply the central pond. Depending on the structure, it is located anywhere from 38-55 feet away from the door of each structure. The maximum water level is 11 inches below the surface of the concrete perimeter. The depth of the central pond was made shallow just in case digging any deeper is not viable. In reality, the pond will be dug as deep as possible to maximize water storage capacity. With a depth of 8 feet, the central pond capacity is designed to hold 3,385 ft3 of water.

In order to support Walipinis, Aquapinis, and Zenapinis needs, a month’s storage of 25,088 ft3 is required, therefore requiring a capacity for 150,529 ft3 of water over a span of 6 months. Water from the existing natural pond can be pumped to the central pond in order to maintain the desired water level. Furthermore, when necessary, the central pond will gravity-overflow to the existing pond.

The water circulation within the indoor growing structures uses a siphon system. This system places the inflow and outflow of the piping at different heights and gravity pulls the water in the downhill direction. The siphon system therefore minimizes energy usage and operational costs. Water flow within all structures with a pond is maintained by one pump. Water gravity feeds from the pond through a drip feeder along the back of the structure. That drip feeder waters the media beds beneath it and drips into a pond below that gravity feeds through the series of all the smaller ponds and is then pumped back into the main pond. Water storage ponds within the greenhouses are an aesthetic feature that also function as a thermal mass to help regulate the temperature within the structures. They provide humidity and house fish that help fertilize the water for the plants that grow in the ponds and media beds. Running water through the media beds feeds the plants there and cleans the water for the fish. The water storage ponds also provide a portion of irrigation to the planted areas within the aquapini and zenapinis. The following images show the water flow of the aquapini/zenapini structure, as well as dimensions of each water retention pond:

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Water Flow within Aquapinis and Zenapinis

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Ponds Supplying Water to Drip Feeders that Water the Media Beds

Starting point: Ponds supplying water to drip feeders that water the media beds. The smaller, lower pond has a pump that pumps water into the larger pond, where the system uses gravity to water the system and is high enough that the percolated water and overflow water gravity feed back to the smaller pond with the pump.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Pond for water percolated through media bed and overflow from supply pond, as well as 1st pond as the water makes its way back to supply pond

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

2nd pond as the recirculation watering system makes its way back to supply pond

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

3rd and final pond as the recirculation watering system makes its way back to supply pond



BERMS AND SWALES

In addition to having sunken indoor growing spaces, berms are used on the north end of the structures, as well as the short outer side. Berms are utilized to capitalize on the insulating properties of soil, which are pretty average when not below the frostline. With this in mind, studies* were then done to determine if the sun we’d get from leaving parts of the East and West transparent would be better than covering these areas with berms. Berms proved to be better than the added sun and the video below shows our studies to demonstrate this:

* Please note that the calculations in the (older design) video above, in all cases except the complete glazed roof, are taking into account a hatch system we were designing that would allow us to insulate the entire structure at night. The complete glazed roof does not include this because it would not be possible with that design. Even though our design is now different from the one shown in this video, the analysis demonstrating the benefits of berms vs. no-berms on the East and West walls are still valid.

Berms are mounds of soil that vary in height and angle depending on its use and design. There was greater benefit to insulate the non-south facing walls with earth using the material that was dug to have sunken indoor growing areas then to have the walls made of material that the sun can penetrate and therefore theoretically warm. The heat gain is greater with berms as compared to large or small windows that would have allowed thermal energy in directly from the sun. This is especially true in northern regions because they don’t get enough sun to make a greenhouse with all glass or light-penetrating walls worthwhile. For these reasons, the north and short outer walls are bermed and the south wall is glass. The east wall is partially bermed and serves as the entrance. The berms help to regulate the temperature and create a more constant inside temperature that is not as dependent on season.

The berms also slow water runoff, and direct it. Berm angles typically range between 25° – 35°. However, the berm angle chosen for our design is 23° because of our soil type (sandy loam) and we plan to create terraces since we may be working with sandy soil. This smaller angle was selected based on the angle of repose of sandy loam. The angle of repose defines the greatest inclined angle between the material and the horizontal plane without the soil sliding or slumping. A smaller angle is preferable in many cases, because it provides exceptional flow properties, also known as the material’s mechanical properties. These qualities are dependent on parameters such as moisture, temperature, and particle size. The less terraces, the better, since terraces require retaining walls, which we plan to make using earthbags. Each terrace is sloped towards the greenhouse walls at a 1 to 2 degree angle.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse


VENTING NETWORK

There are empty pipes leading from each structure that function as cooling-vents for the structures. These pipes draw cool air off of the Central Pond in order to ventilate the structures during warm weather seasons. The negative internal pressure needed to create the “pull” for this air is created by vents that will open at the tops of the structures anytime the temperature in the structures gets too high. As outdoor temperatures rise, so will the temperatures indoors and in order to reduce energy of ventilating six large structures, the cooling vent pipes provide a sustainable alternative.

This venting system utilizes 8-1/8 inch diameter pipes. The lengths of the pipes vary depending on the location of the structure and its proximity to the central pond, as well as elevation change of the site. The pipe lengths provided below do not take into account changes in elevation (which for our design is 6-1/2 feet at the most):

  • Pipes leading to Walipini 1 and 2 are 78 linear feet.
  • Pipe leading to the Walipini 3, Large-scale Production Aquapini are 40 linear feet, because it is closest to the pond.
  • Pipes leading to the Zenapini 1 and 2 are 53 linear feet.

These pipes can be used for water too, because they slope downward to the central pond. Their main function though is to draw cool and moist air off the pond and into the structures.



ANCILLARY BENEFITS



SEATING AREAS

The top of the pond includes a design feature which allows it to be covered and used as a presentation stage. Seating is placed around the central pond in order to provide a location to host events. The design includes 4 rows of seating, having a level designated for ADA seating. The elevation of each level is a 6” difference to provide easy viewing from each row behind another. All together the seating area accommodates 95 individuals. The ADA row provides spacing for 17 wheelchairs or an additional 78 persons. Therefore, the total seating capacity in this area is around 170 people. The surrounding paved and landscaped areas provide standing room and additional seating for hundreds more.

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Central Pond that can be converted to a stage. Steps provide comfortable seats.



CIRCULATION

The pathway circulation (i.e. flow patterns of people) of the site allows proper ADA access to the central seating area around the pond and the structures. Each ADA access point is 4’ wide with a change in elevation of 1 foot per 12 feet, creating an 8% slope. To establish proper service truck access, entrances are designed at 10’ wide along with a circulation path 16’ wide around the central pond.



RECREATION AREAS

The site includes 4 recreational areas. They are situated North-east, North-west, South-east, and South-west of the layout. These recreational and relaxation areas are purposed to encourage outdoor activities for children and adults. The design consists of 4 areas leveled 6’ above the structures’ finish grade.



PREVIOUS DESIGN RESEARCH



CURRENT ROOF DESIGN RESEARCH

MORE SUNLIGHT STUDIES – CLICK IMAGES TO ENLARGE

Seasonal Direct Sunlight – Annual Direct Sunlight – Direct & Indirect Light

Walipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouseWalipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouseWalipini, Aquapini, Zenapini, Infrastructure Layout, Highest Good food infrastructure, greenhouse

Here is a skylight study we did for these designs. It was to test the difference between flush skylights, horizontal skylights, 50% versus 100% solar penetration, and the addition of reflective surfaces versus non-reflective surfaces. The results show that flush skylights combined with 100% solar penetration and the addition of reflective surfaces will maximize sunlight in these structures and increase this sunlight where we will need it most: against the North wall. The skylights in this video are placed 8′ from the North wall (shown) and (for easier viewing of the anelemma) the wall is only 5′ high, placing the ground at grade versus 6.5′ below grade as it will be in the walipinis and aquapinis.



RESOURCES



SUMMARY

open source building plans, open source architectural plans, open source structural plans, open source blueprints, open source CAD, open source Sketchup, open source 3D Max, open source Revit, free-shared plans, free-shared blueprints, sustainable food, best practice food, sustainable food systems, green food, aquapinis, aquapini, walipini, green house, in-ground growing, organic food, One Community, open source food, free-shared architecture, sustainable living, green living, eco living, living ecologically, for The Highest Good of All, transforming the world, build your own food house, build your own greenhouse, affordable food, open source architecture, architects of the future, sustainability non-profit, 501c3 organization, sustainable life, water catchment, organic food, eco-housing, artistic homes, sustainability cooperative, sustainable living group, open source, sustainability nonprofit, free-shared plans, teacher/demonstration village, open source project-launch blueprinting, One Community housing, Highest Good housingOne Community’s Phase II food infrastructure consists of 6 different indoor growing structures that we are open source project-launch blueprinting. There are three primary designs: Large-scale Production AquapiniAesthetic and Diversity Focused Zen Aquapini, and the Maximally-affordable Walipini Greenhouse Design. Each of the 6 structures will provide a different internal environment and grow a different variety of food. The structures will be the Large-scale Production Tropical AquapiniZen Aquapini #1: Cloud Forest HouseZen Aquapini #2: Tropical Moist HouseWalipini #1: Frost-free Arid Zone Desert HouseWalipini #2: Borderline Subtropical House, and the Walipini #3: Tropical House. These 6 structures will be a part of our botanical garden model and will produce a diversity of delicious and nutritious food far beyond anything found in a typical grocery store.



FREQUENTLY ANSWERED QUESTIONS

Q: Will you be getting permits for these structures?

Yes, all of our food structures will be permitted and we will be open source sharing the permitting process also.

Q: How much will these structures cost to build?

Please see our open source aquapini and walipini cost analysis page.

Q: How much food will these structures produce?

Please see our open source aquapini and walipini planting and harvesting page.

Q: What is One Community’s stance on pesticides, herbicides, and fungicides?

If it is not safe to eat, we will not be spraying it on our food.

Q: Is One Community going to be a vegetarian community?

The One Community team consists of vegans, vegetarians, and omnivores. In accordance with our philosophy for The Highest Good of All we are maintaining a non-idealogical approach to food choices. That said, also in accordance with this philosophy, we will only support and consume food items that are ethically and sustainably raised, managed, and produced. The consensus process will be used to decide the evolution of the One Community food plan.

Q: How do you intend to produce spices, mill grain for flour, produce cooking oil, etc. etc.

To us, “100% food sustainability” means we will demonstrate and open source share a model that doesn’t need external food sources. Having achieved this, what we produce internally versus choosing to buy will be decided through the consensus process.

Q: The Walipini, Aquapini, and Zenapini structures are closed-loop systems, will you be supplementing them with CO2 to improve plant growth?

Based on the research we did, we believe that we should not be concerned about the CO2 levels in our growing structures. The CO2 generated by the decomposition of organic material within these structures, from the plants themselves at night, people working in and visiting the structures, and from outside when people enter and exit will be sufficient. Recent research also showed that excessive CO2 can actually be detrimental to the nutritional value of plants. Intentional increases to 1500 ppm (for production increases of 30%) can be created by various means but this extra CO2 decreases levels of key nutrients while also creating excess carbohydrate/sugar content. This results over the long run in plants becoming more like junk food than the nutritions foundations of a healthy diet they are meant to be.



One Community
